Directional Couplers

DCS102

This series offers UHF octave band coverage in a relatively small overall outline configuration. Varied coupling values facilitate multiple applications and this design also permits usage as a bi-directional coupler, allowing the sampling of incident and reflected power. Design package accommodates SMA, N, BNC and TNC connectors. Design modification may be necessary for non-SMA connectors.

FEATURES:

  • Low Insertion Loss
  • Octave Band Coverage
  • Compact Configuration
  • Standard SMA Connectors (N, BNC, TNC optional)

Finish: Chemical Conversion Coating per MIL-DTL-5541 Class 3 (optional paint available upon request)
Marking: All units supplied with P/N and date code on polyester label (special marking available upon request)
Electrical Test: All units tested on a Go/No-go basis (plotted data available upon request). Specifications indicated are subject to change. Unless otherwise specified, electrical properties correspond to use with standard SMA connectors. Insertion loss excludes coupled power.
Dimensions: All dimensions are expressed in inches, (1 inch = 25.4mm). All dimensions indicated are subject to change. Unless otherwise specified, tolerances for decimals are ±0.02 for .XX and ±0.005 for .XXX. Tolerances for angles are ±0°30'.
Temperature: Units designed to operate -55° to +85° C.

General Parameters:
Type: Octave Band Couplers
Frequency: 0.225 to 0.400 GHz
Low Frequency [MHz]: 1000
High Frequency [MHz]: 2000
Insertion Loss [dB]: 0.1
Coupling [dB]: 10
VSWR 1 [:1]: 1.10:1
VSWR 2 [:1]: 1.10:1
Input Power [W]: 50
Directivity [dB]: 25
Coupling Variation: 0.5
Power Incident: 50
Power Reflected: 5
Peak Power: 3
